Description
| Design |
In-wall, 2-way TSLB magnetically mounted grill TEI mounting bracket TIMPC enclosure TEC binding posts |
| Power handling |
100W MAX 75W RMS |
| Frequency response | 42Hz - 20kHz |
| Impedance | 8ohm |
| Sensitivity | 90dB |
| High-frequency driver |
25 mm (1”), TPTTD Swivel mount ±3dB treble switch |
| Bass-Midrange driver | 133 mm (5.25”), Kevlar® |
| Dimensions (H x W x D or Dia x D) | 26.7 x 17.5 x 7.5 cm |
| Cutout Dimensions (H x W or Dia) | 24.5 x 15.3 cm |
| Minimum Mounting Depth | 7.5 cm |
| Weight | 1.25 kg / pc. |
