Description
| Design |
In-wall, 2-way TSLB magnetically mounted grill TEI mounting bracket TIMPC enclosure TEC binding posts |
| Power handling |
130W MAX 100W RMS |
| Frequency response | 40Hz - 20kHz |
| Impedance | 8ohm |
| Sensitivity | 90dB |
| High-frequency driver |
25 mm (1”), TPTTD Swivel mount ±3dB treble switch |
| Bass-Midrange driver | 165 mm (6.5”), Kevlar® |
| Dimensions (H x W x D or Dia x D) | 30 x 20.5 x 8.7 cm |
| Cutout Dimensions (H x W or Dia) | 28 x 18.5 cm |
| Minimum Mounting Depth | 9 cm |
| Weight | 1.7 kg / pc. |
