| DISPLAY |
- Type: TI DMD 0.65
- Resolution (Native): 1920x1080 (Full HD)
- F Stop / Focal Length mm: 2.54
- Focus / Zoom: Adjustable by OSD menu / N/A
- Keystone: H:+/-30° , V:+30°/-12°
- Auto keystone: Yes (Vertical)
- Display Size: 80" ~ 150"
- Throw Distance: 0.43 m ~ 0.8 m
- Throw Ratio: 0.23
- Lamp Power: 390 W
- Lamp Life (Normal / SuperEco Mode): 15,000 / 20,000 (Ecco mode) (hours)
- Brightness: 4,500 ANSI Lumens
- Contrast Ratio: 100,000:1
- Color Depth: 1.07 Billion Colors (30 bits per color)
- Optical Offset : 137.6 +-5%
|
| AUDIO |
Speaker: 8W Cube x2 |
| INPUT SIGNAL |
Video: 480i and 576i, 480p and 576p, 720p, 1080i, 1080p
Frequency (H/V): 15 ~ 100 KHz / 24 ~ 120 Hz |
| COMPATABILITY |
- PC: Support up to 1920x1080@60Hz
- Mac: Support up to 1920x1080@60Hz
|
| CONNECTOR |
- VGA Input: x2
- VGA Output: x1
- Digital Input: HDMI x1 / HDMI (MHL2.0) x1
- Composite Input: RCA x1
- S-Video Input: x1
- Component: x2 (Share with VGA input )
- Audio Input: 3.5mm mini jack x1, RCA(L/R) x1
- Audio Output: 3.5mm mini jack x1, RCA(L/R) x1
- Control: RS-232
- USB: Type A x1 (Power Charging) / Mini type B x1 (Maintenance and mouse control) / Micro USB Wire x1 (Power Charging)
- Lan: x1
- 3D VESA: x1
- DC Output: x1
|
| POWER |
- Voltage: 100~240Vac 50/60Hz (Auto Switching)
- Power Consumption: 450 W (Max.)
- Standby: <0.5W
|
| OPERATING CONDITION |
- Temperature: 0°C ~ 40°C (32°F ~ 104°F)
- Humidity: 0% ~ 90% (non-condensing)
- Altitude: 0 ~ 6,000 ft, operational up to 10,000 ft at reduced reliability and performance
|
| NOISE LEVEL |
Normal / Eco Mode: 28dB (Eco Mode) |
| DIMENSIONS |
Physical (WxDxH): 508 x 392 x165 mm/ 20” x 15.43 ” x 6.5” |
| WEIGHT |
Net: 13.6 kgs / 29.96 lbs |
| REGULATIONS |
CB, cTUVus, FCC, CE. EMC, CCC, GS, RCM |
| PACKAGE CONTENTS |
1. Power Cord, 1.8m, black 1 2. VGA Cable, 1.8m, black x 1 3. Remote Control with Batteries (With Laser pointer) x1 4. Quick Start Guide (one sheet version) x1 5. ViewSonic CD Wizard (With User Manual) x 1 6. HDMI Cable |
