Subwoofer Array Driver Enclosure Type |
Acoustic Suspension with Color-Impregnated Resin Shell |
Subwoofer Array Driver Complement |
• (1) 10" (25.4 cm) d (Round) Long-throw Dynamic Balance composite cone driver with dual voice coils and butyl rubber surround - Subwoofer - Voice Coil 2" (5.08 cm) d |
Height |
11" (27.94 cm) |
Width |
16.9" (42.93 cm) |
Depth |
16.9" (42.93 cm) |
Weight |
16.75 lbs (7.6 kg) |
Nominal Impedance |
8 ohms |
Sensitivity (1 watt @ 1 meter) |
88 dB |
Lower and Upper -3dB Limits |
50 Hz → 110 Hz |
Recommended Amplifier Power Per Channel |
10 watts → 200 watts |
Peak Power Handling |
200 watts |
Midrange/Woofer Crossover Frequency |
150 Hz |
Power Handling (per channel) |
10 watts → 200 watts |
Mounting Type |
Security eyebolt |
Available Orientations |
Horizontal |
Mounting Type |
Keyhole Slots |
Available Orientations |
Horizontal |
